Application scenarios:
Production and assembly of energy storage liquid cooled packs:
Including processes such as liquid cooling board online, liquid cooling board airtightness testing, liquid cooling board cleaning and insulation sheet pasting, liquid cooling board gluing, module box insertion, module resetting, connector installation, bronze plate installation, sampling line installation, accessory installation, EOL testing, box cover installation, whole package airtightness testing, labeling offline, etc
Adjust the process and tooling to be compatible with the production and assembly of energy storage air-cooled packs.
Product Features
● Transportation method: drum line/roller line; Suitable conveying methods can be selected based on product size, weight, and on-site location
● According to the product structure, processes such as liquid cooling plate online, module in box, module fastening, box cover installation, and whole package offline can be used as automatic workstations
● The operation interface supports switching between Chinese and English
● Safety: The automatic workstation adopts a fully enclosed structure, with standard safety doors, safety interlock devices, clear electrical and mechanical safety signs, and high safety
● Compatibility: Compatibility can be achieved by adjusting the formula and fixtures
● Intelligent monitoring: Key processes are equipped with intelligent monitoring both internally and externally, ensuring intelligent safety
● MES: The data generated by each workstation can be independently uploaded to the company's MES, and the production product data, process data, and process data can be traced. It supports MES system access and independent operation of edge servers. Realize optimized management from production order issuance, production process data collection to product completion offline, help enterprises improve production management level, achieve lean manufacturing, enhance product quality, and reduce production costs;
● Real time: Collect data and information in real-time during the production process, and make corresponding analysis, processing, and rapid response.
